Submersible Pumps





Process Pump & Seal, Inc. is your local solutions provider for submersible pump applications. We have the experience, knowledge, and expertise to properly identify the best pump for your process. We are a distributor for the below manufacturers (please click the logo or text below ! ) :



                                    BJM Pumps                                                            Mody Pumps

Manufacturer Spotlight: BJM Pumps

At Process Pump & Seal, we offer BJM submersible pumps to meet the demands of your operation's environment. We stock a variety of their submersible pumps at our Trenton OH facility to encourage the fastest delivery. Below are some of the styles of submersible pumps we carry:

  • General Dewatering
  • Sand, Sludge and Slurry
  • Hydraulic
  • Solids Handling
  • Corrosion Resistant
  • Hight Temp (up to 200 deg F)
  • Explosion Proof
  • MSHA Approved Pumps



Video: BJM RAD-AX Submersible - Radial / Axial - Shredder / Cutter Pump

Electric Submersible Pumps with Shredder Action Impellers for Municipal, Industrial and Agricultural Waste-Water



Featured : BJM SK Series Submersible

The Shredder (SK) pumps leave solids slightly larger than if passed through a grinder pump. The shredding action is caused by using a cutting impeller with a Tungsten Carbide Tip, against a "spiral" shaped diffuser plate.

Benefits

Longer Power Cord – Standard 33ft. power.

  • 304SS Motor Housing – Superior abrasion resistance will not wear out like aluminum motor housings when pumping sandy water.

  • Explosion Proof Option as well as 316 Cast Stainless Option.

  • Three Seal Motor Protection - Motor is protected by double mechanical seals. Lower seal made of silicon carbide/silicon carbide and upper seal is made of carbon/ceramic. An additional lip seal has been installed above the impeller, to help prevent abrasives such as dirt, silt or sand, from entering into the seal chamber.

  • More Motor Protection – Winding protection and (NEMA) Class F motor insulation allows motor temperature to raise to 230°F, superior to pumps with Class A and B insulation. Automatic switch turns pump motor off if temperature and/or amp draw raises too high. When the motor cools the switch will automatically reset and the pump will turn back on.

  • Tough Pump Construction – Hardened cast iron stands up to rough handling and pumping sandy water unlike pumps with soft resin impellers or plastic exterior components.

Series Curve
